No. of sale: 310326P
Starting date
ManufacturerSHENZHEN ZHONGLIDA MACHINERY ModelZLD008A-5 Year2015 ObservationsCNC Polyurethane Foam Cutting Machine
Cutting Method: Circular Knife Cutting
Cutting Size: 2500 x 2000 x 1200 mm
Working Speed: 0-10 m/min, adjustable
Cutting Accuracy: ±1.0 mm
Knife Specifications: 11440 mm x 3 mm x 0.6 mm, Ring Serrated Knife
Knife Linear Speed: Adjustable speed, 0-1200 m/min
Drive Motor: AC Servo System (X, Y axes)
Uses a 1.5 kW servo motor for the main blade and a 0.75 kW servo motor for the rotary blade
Control System: PC computer + multi-axis motion control board
Software: Special sponge cutting system ZLD
Power: AC380V/10KW
Dimensions: 6000x4200x3200mm
Weight: 3500 kg
ManufacturerSHENZHEN ZHONGLIDA MACHINERY ModelZLD008A-5 Year2015 ObservationsCNC Polyurethane Foam Cutting Machine
Cutting Method: Circular Knife Cutting
Cutting Size: 2500 x 2000 x 1200 mm
Working Speed: 0-10 m/min, adjustable
Cutting Accuracy: ±1.0 mm
Knife Specifications: 11440 mm x 3 mm x 0.6 mm, Ring Serrated Knife
Knife Linear Speed: Adjustable speed, 0-1200 m/min
Drive Motor: AC Servo System (X, Y axes)
Uses a 1.5 kW servo motor for the main blade and a 0.75 kW servo motor for the rotary blade
Control System: PC computer + multi-axis motion control board
Software: Special sponge cutting system ZLD
Power: AC380V/10KW
Dimensions: 6000x4200x3200mm
Weight: 3500 kg
Start price 17.500 €
ManufacturerBRANSON - EMERSON GROUP ModelIR 170/80 Si Year2014 ObservationsInfrared Welding Machine for Polystyrene Plastics
CIT metal sheet heaters emit infrared wavelengths tailored to the absorption characteristics of most polymers. The result is more efficient heat transfer to the parts and shorter cycle times.
A range of applications: CIT is ideal for the clean and precise joining of parts such as automotive instrument panels, fluid tanks, vehicle interiors, small appliances, medical technology products, or any part or product requiring a clean weld that maximizes aesthetics, integrity, and functionality.
Tool data
Upper mounting Table area (H x W, max. height above ground) [mm]: 1700 x 800, 2300
Usable area (H x W) [mm]: 1700 x 800
Bottom mounting Table area (H x W, min. height above ground) [mm]: 1700 x 800, 600
Usable area (H x W) [mm]: 1700 x 800
Lower Mounting Table Area (H x W, min. height above ground) [mm]: 1700 x 800, 600
Usable Area (H x W) [mm]: 1700 x 800
IR Tool Holder: Table Area (H x W, average height above ground) [mm]: 1700 x 800, 1400
Mechanical Working Area (H x W) [mm]: 1700 x 800
Usable Area (H x W) [mm]: 1700 x 800
Max. Clearance between upper and lower tables [mm]: 1700
Min. Clearance between upper and lower tables [mm]: 550
Max. Weight Upper tool / lower tool / IR mirror [kg]: 250 / 250 / 150
Axes
Lower tool axes (speed / travel / control): 500 mm/s / 500 mm / 20000 N
position
Upper tool axes (speed / travel / control): 500 mm/s / 750 mm / 20000 N
position
IR axes (speed / travel / control): 1000 mm/s / 1100 mm / position
Welding force control (lower tool axis): closed regulating circuit
Machine Dimensions
Overall dimensions (H x W x D) [mm]: 3040 x 2480 x 4140
Dimensions with doors open (H x W x D) [mm]: 3040 x 3080 x 4740
Weight [kg] Approx. 8000
Machine Control
PLC Model (standard, alternative, see spec.): Realtime Soft-SPS, IEC 1131, CAN open
OP Model (standard, alternative, see spec.): Branson Industrial PC, IR-100
Welding and Tool Control
IR: Heating time, power
Assembly: Welding time, absolute weld depth
Configuration: Steplessly adjustable for all functions
Presets: Encoded 15 times
Data Logging: One set of data per weld
Pneumatic System
Model (standard, alternative, see spec.): Festo
Compressed air supply [bar]: 6
Functions (standard, special version, compare offer): Software function 8 (no pneumatic valves on the machine)
IR Connection
Model: Branson IR-Power
Control: Closed regulating circuit
Supply voltage: 3 x 400 V AC, N, PE, 60 Hz; Safe low voltage
Number of heating circuits: 1 to 16 depending on the tool, more than 16 with external distribution cabinets
Acoustic protection
Noise emission (DIN 45635) [dBA]: 65.7
Front door (model; H x W, height above ground) [mm]: Clear Makrolon; 1200 (2x600) x 850; 850
Color (standard, alternative, see spec.): RAL 7035, RAL 7011
Connections (standard, special equipment)
Pneumatic system: R 1/2"
Supply voltage: 3 x 400 V AC, N, PE, 60 Hz
Power socket [mm]/ Max. current (main fuse) [A] (tool)/ Power supply:
See electrical diagram (depending on machine/tool spec.)
Data interface: USB port, LAN
ManufacturerBRANSON - EMERSON GROUP ModelIR 170/80 Si Year2014 ObservationsInfrared Welding Machine for Polystyrene Plastics
CIT metal sheet heaters emit infrared wavelengths tailored to the absorption characteristics of most polymers. The result is more efficient heat transfer to the parts and shorter cycle times.
A range of applications: CIT is ideal for the clean and precise joining of parts such as automotive instrument panels, fluid tanks, vehicle interiors, small appliances, medical technology products, or any part or product requiring a clean weld that maximizes aesthetics, integrity, and functionality.
Tool data
Upper mounting Table area (H x W, max. height above ground) [mm]: 1700 x 800, 2300
Usable area (H x W) [mm]: 1700 x 800
Bottom mounting Table area (H x W, min. height above ground) [mm]: 1700 x 800, 600
Usable area (H x W) [mm]: 1700 x 800
Lower Mounting Table Area (H x W, min. height above ground) [mm]: 1700 x 800, 600
Usable Area (H x W) [mm]: 1700 x 800
IR Tool Holder: Table Area (H x W, average height above ground) [mm]: 1700 x 800, 1400
Mechanical Working Area (H x W) [mm]: 1700 x 800
Usable Area (H x W) [mm]: 1700 x 800
Max. Clearance between upper and lower tables [mm]: 1700
Min. Clearance between upper and lower tables [mm]: 550
Max. Weight Upper tool / lower tool / IR mirror [kg]: 250 / 250 / 150
Axes
Lower tool axes (speed / travel / control): 500 mm/s / 500 mm / 20000 N
position
Upper tool axes (speed / travel / control): 500 mm/s / 750 mm / 20000 N
position
IR axes (speed / travel / control): 1000 mm/s / 1100 mm / position
Welding force control (lower tool axis): closed regulating circuit
Machine Dimensions
Overall dimensions (H x W x D) [mm]: 3040 x 2480 x 4140
Dimensions with doors open (H x W x D) [mm]: 3040 x 3080 x 4740
Weight [kg] Approx. 8000
Machine Control
PLC Model (standard, alternative, see spec.): Realtime Soft-SPS, IEC 1131, CAN open
OP Model (standard, alternative, see spec.): Branson Industrial PC, IR-100
Welding and Tool Control
IR: Heating time, power
Assembly: Welding time, absolute weld depth
Configuration: Steplessly adjustable for all functions
Presets: Encoded 15 times
Data Logging: One set of data per weld
Pneumatic System
Model (standard, alternative, see spec.): Festo
Compressed air supply [bar]: 6
Functions (standard, special version, compare offer): Software function 8 (no pneumatic valves on the machine)
IR Connection
Model: Branson IR-Power
Control: Closed regulating circuit
Supply voltage: 3 x 400 V AC, N, PE, 60 Hz; Safe low voltage
Number of heating circuits: 1 to 16 depending on the tool, more than 16 with external distribution cabinets
Acoustic protection
Noise emission (DIN 45635) [dBA]: 65.7
Front door (model; H x W, height above ground) [mm]: Clear Makrolon; 1200 (2x600) x 850; 850
Color (standard, alternative, see spec.): RAL 7035, RAL 7011
Connections (standard, special equipment)
Pneumatic system: R 1/2"
Supply voltage: 3 x 400 V AC, N, PE, 60 Hz
Power socket [mm]/ Max. current (main fuse) [A] (tool)/ Power supply:
See electrical diagram (depending on machine/tool spec.)
Data interface: USB port, LAN
Start price 95.000 €
