HAIFU Mod. JC

No. of sale: 300419F

Starting date
29/03/2019 20:00:00
Closing Date
09/05/2019 20:00:00
Viewing days
by appointment
Location
Milán (Italy)
Tender sale of high intensity extracorporeal ultrasound equipment; Brand: Chongquing Haifu Technology Co. ,, model: JC (2010), 0 hours of use. It is packed,
sales commission
10% buyers premium
Payment methods

Manufacturer
Chongqing Haifu Medical Technology
Model
JC
Year
2010
No. Series
056
Observations
In their original packaging and in perfect condition. Unused.
Non-invasive extracorporeal ultrasound ablation treatment of tumors.
Main parameters: Acoustic focusing efficiency: 28.000 W/cm2; focal region: 1.1x1.1x3.3mm; max. Acoustic power: 400W; Side lobe: <-10dB; maximum range of transducer movement: X: 120mm; Y: 120mm; Z: 180mm; movement control accuracy: +-0,1mm; accumulated tolerance in linear movement: +-1mm; Therapeutic frequency: 0.8-2.4MHz; probe vertical movement range: 0-100mm; probe rotating angle range: +-90º; dissolved oxygen: <3ppm; electric power: 12.5KVA; Installation Environment: Room requirement: Area: >40m2, Width: >5m; power requirement: 3ph, five-wire power cable with ground wire which in conformity with local laws; water requirement: Flow: >1m3/h; Pressure: 0.1-0.5MPa. Total hours working: 0 Hours.



Start price 500.000 €

Manufacturer
Chongqing Haifu Medical Technology
Model
JC
Year
2010
No. Series
056
Observations
In their original packaging and in perfect condition. Unused.
Non-invasive extracorporeal ultrasound ablation treatment of tumors.
Main parameters: Acoustic focusing efficiency: 28.000 W/cm2; focal region: 1.1x1.1x3.3mm; max. Acoustic power: 400W; Side lobe: <-10dB; maximum range of transducer movement: X: 120mm; Y: 120mm; Z: 180mm; movement control accuracy: +-0,1mm; accumulated tolerance in linear movement: +-1mm; Therapeutic frequency: 0.8-2.4MHz; probe vertical movement range: 0-100mm; probe rotating angle range: +-90º; dissolved oxygen: <3ppm; electric power: 12.5KVA; Installation Environment: Room requirement: Area: >40m2, Width: >5m; power requirement: 3ph, five-wire power cable with ground wire which in conformity with local laws; water requirement: Flow: >1m3/h; Pressure: 0.1-0.5MPa. Total hours working: 0 Hours.



Start price 500.000 €

Sold
1  -  Extracorporeal high-intensity focused ultrasound equipment
500.000 €
