No. of sale: 190520M
Starting date
ManufacturerHaas ModelST-30Y Year2016 Observations CNC LATHE HAAS ST-30Y
Including Haas Bar Feeder HAAS301
SWING DIAMETER
Over Front Apron 806 mm
Over Cross Slide 527 mm
Over Tailstock 584 mm
CAPACITIES
Chuck Size 254 mm
Max Cutting Diameter (varies with turret) 533 mm
Max Cutting Length (varies with workholding) 660 mm
Bar Capacity 76 mm
Between Centers 762 mm
TRAVELS
X Axis 318 mm
Z Axis 660 mm
FEEDRATES
Rapids on X 24.0 m/min
Rapids on Z 24.0 m/min
AXIS MOTORS
Max Thrust X 18238 N
Max Thrust Z 22686 N
SPINDLE
Spindle Nose A2-6
Max Rating 22.4 kW
Max Speed 3400 rpm
Max Torque 407 Nm @ 500 rpm
Max Torque w/opt Gearbox 1356 Nm @ 150 rpm
Spindle Bore ø 88.9 mm
TURRET
Number of Tools 12-Station BOT
OD vs ID Tools Any Combination (will vary with turret)
Boring Bar Rear Clearance (from back of turret ) 102.0 mm
GENERAL
Coolant Capacity 208 L
AIR REQUIREMENTS
Air Required 113 L/min @ 6.9 bar
Inline Air Hose 3/8 in
Coupler (Air) 3/8 in
Air Pressure Min 5.5 bar
ELECTRICAL SPECIFICATION
Spindle Speed 3400 rpm
Drive System Direct Speed, Belt Drive
Spindle Power 22.4 kW
Input AC Voltage (3 Phase) - Low 220 VAC
Full Load Amps (3 Phase) - Low 70 A
Input AC Voltage (3 Phase) - High 440 VAC
Full Load Amps (3 Phase) - High 35 A
DIMENSIONS - SHIPPING
Domestic Pallet 435 cm x 229 cm x 249 cm
Export Pallet 435 cm x 229 cm x 249 cm
Weight 6487.0 kg
ManufacturerHaas ModelST-30Y Year2016 Observations CNC LATHE HAAS ST-30Y
Including Haas Bar Feeder HAAS301
SWING DIAMETER
Over Front Apron 806 mm
Over Cross Slide 527 mm
Over Tailstock 584 mm
CAPACITIES
Chuck Size 254 mm
Max Cutting Diameter (varies with turret) 533 mm
Max Cutting Length (varies with workholding) 660 mm
Bar Capacity 76 mm
Between Centers 762 mm
TRAVELS
X Axis 318 mm
Z Axis 660 mm
FEEDRATES
Rapids on X 24.0 m/min
Rapids on Z 24.0 m/min
AXIS MOTORS
Max Thrust X 18238 N
Max Thrust Z 22686 N
SPINDLE
Spindle Nose A2-6
Max Rating 22.4 kW
Max Speed 3400 rpm
Max Torque 407 Nm @ 500 rpm
Max Torque w/opt Gearbox 1356 Nm @ 150 rpm
Spindle Bore ø 88.9 mm
TURRET
Number of Tools 12-Station BOT
OD vs ID Tools Any Combination (will vary with turret)
Boring Bar Rear Clearance (from back of turret ) 102.0 mm
GENERAL
Coolant Capacity 208 L
AIR REQUIREMENTS
Air Required 113 L/min @ 6.9 bar
Inline Air Hose 3/8 in
Coupler (Air) 3/8 in
Air Pressure Min 5.5 bar
ELECTRICAL SPECIFICATION
Spindle Speed 3400 rpm
Drive System Direct Speed, Belt Drive
Spindle Power 22.4 kW
Input AC Voltage (3 Phase) - Low 220 VAC
Full Load Amps (3 Phase) - Low 70 A
Input AC Voltage (3 Phase) - High 440 VAC
Full Load Amps (3 Phase) - High 35 A
DIMENSIONS - SHIPPING
Domestic Pallet 435 cm x 229 cm x 249 cm
Export Pallet 435 cm x 229 cm x 249 cm
Weight 6487.0 kg
Start price 55.000 €
