No. of sale: 140420M
Starting date
ManufacturerXH Model2310x18 Year2016 ObservationsProduct main technical parameters:
Specifications Units XK(H)2310
Table size mm 1000x1800
Max. load working table kg 3500
Gantry width mm 1200
Table travel (X.Y.Z) mm 1700x400
T-type slot numbers / width /space mm 7-22x140
The moving direction of travel of working table mm 1950
The sliding seat moving direction of travel mm 1200
Spindle up and down movement direction travel mm 760
Distance from spindle end to platform mm 110-870
Spindle specification (model / installation diameter) mm BT50-φ155(φ190)
Spindle speed r/min 6000
Fast moving X.Y axis mm/min 10000
Fast moving Z axis mm/min 5000
Feed speed (X.Y.Z) mm/min 5-5000
Spindle motor power KW 15
Control FANUC
X.Y.Z shaft motor torque N. m 30/22/22
X.Y axis positioning accuracy mm 0.025
Z axis positioning accuracy mm 0.018
X.Y axis repeat positioning accuracy mm 0.012
Z axis repeat positioning accuracy mm 0.010
Tool magazine capacity piece 18
X/Y axis guide rail Sliding guide
Z axis guide rail Sliding guide
Weight of machine tool T 15
ManufacturerXH Model2310x18 Year2016 ObservationsProduct main technical parameters:
Specifications Units XK(H)2310
Table size mm 1000x1800
Max. load working table kg 3500
Gantry width mm 1200
Table travel (X.Y.Z) mm 1700x400
T-type slot numbers / width /space mm 7-22x140
The moving direction of travel of working table mm 1950
The sliding seat moving direction of travel mm 1200
Spindle up and down movement direction travel mm 760
Distance from spindle end to platform mm 110-870
Spindle specification (model / installation diameter) mm BT50-φ155(φ190)
Spindle speed r/min 6000
Fast moving X.Y axis mm/min 10000
Fast moving Z axis mm/min 5000
Feed speed (X.Y.Z) mm/min 5-5000
Spindle motor power KW 15
Control FANUC
X.Y.Z shaft motor torque N. m 30/22/22
X.Y axis positioning accuracy mm 0.025
Z axis positioning accuracy mm 0.018
X.Y axis repeat positioning accuracy mm 0.012
Z axis repeat positioning accuracy mm 0.010
Tool magazine capacity piece 18
X/Y axis guide rail Sliding guide
Z axis guide rail Sliding guide
Weight of machine tool T 15
Start price 45.000 €
ManufacturerXH Model7134 Year2016 ObservationsProduct main technical specifications:
Specifications XH7134
Table size 940×340 mm
X-axis travel 600 mm
Y-axis travel 340 mm
Z-axis travel 450 mm
Spindle Taper BT40
Spindle speed 100-8000 R/min
Cutting feed rate(X/Y/Z) 10 m/min
Spindle nose to table 120-470 mm
Machine weight 2.5 Tns.
Capacity: 16 tools.
Dimensions 2250×2200×2400 mm
ManufacturerXH Model7134 Year2016 ObservationsProduct main technical specifications:
Specifications XH7134
Table size 940×340 mm
X-axis travel 600 mm
Y-axis travel 340 mm
Z-axis travel 450 mm
Spindle Taper BT40
Spindle speed 100-8000 R/min
Cutting feed rate(X/Y/Z) 10 m/min
Spindle nose to table 120-470 mm
Machine weight 2.5 Tns.
Capacity: 16 tools.
Dimensions 2250×2200×2400 mm
Start price 12.000 €
