No. of sale: 051219M
Starting date
ManufacturerAxial ModelPHSE 135 CNC Year2005 Observations Folding length: 3,000 mm; Power: 135 Tn.;
Control Cybelec DNC 60 to 4 axes (Y1, Y2, X, R);
Distance between mullions: 2600 mm; Swan neck: 315 mm; Stroke: 200 mm;
Approach speed: 97 mm/sec; Folding speed: 8 mm/sec; Return speed: 107 mm/sec;
Stop time: 100 ms.;Safety distance: 160 mm.;
Self-centering slotted table;Table width: 95 mm;
Rear stop with 4 retractable fingers;
Punch tie Ajial Colly;
Hydraulic group Rexroth;
Engine: 11 KW;
Weight: 10 Tn;
CE certificate.
Weight10000kg
ManufacturerAxial ModelPHSE 135 CNC Year2005 Observations Folding length: 3,000 mm; Power: 135 Tn.;
Control Cybelec DNC 60 to 4 axes (Y1, Y2, X, R);
Distance between mullions: 2600 mm; Swan neck: 315 mm; Stroke: 200 mm;
Approach speed: 97 mm/sec; Folding speed: 8 mm/sec; Return speed: 107 mm/sec;
Stop time: 100 ms.;Safety distance: 160 mm.;
Self-centering slotted table;Table width: 95 mm;
Rear stop with 4 retractable fingers;
Punch tie Ajial Colly;
Hydraulic group Rexroth;
Engine: 11 KW;
Weight: 10 Tn;
CE certificate.
Weight10000kg
Start price 29.500 €
ManufacturerAjial ModelPHA 83 Year2019 ObservationsNEW BRAND
Power: 80 Tn; Folding length: 3,200 mm;
2 axes (X,Y); With control. ESA S625;
Step between mullions: 2.650 mm; Swan neck: 320 mm;
Table top opening: 370 mm; Cylinder stroke 120 mm;
Anti-torque bar; Engine power: 7.5 Kw;
74x74 mm multi-uve matrix;
C.E. Certificate.
ManufacturerAjial ModelPHA 83 Year2019 ObservationsNEW BRAND
Power: 80 Tn; Folding length: 3,200 mm;
2 axes (X,Y); With control. ESA S625;
Step between mullions: 2.650 mm; Swan neck: 320 mm;
Table top opening: 370 mm; Cylinder stroke 120 mm;
Anti-torque bar; Engine power: 7.5 Kw;
74x74 mm multi-uve matrix;
C.E. Certificate.
Start price 25.500 €
