Manufacturer
LAGUN
Model
FU-110
Observations
TABLE
Work surface 1100 x 250 mm
Number of T-slots 3
Distance between slots 63
Table rotation both senses 45

COURSE
Long. Automatic 750 mm.
Transv. Automatic 280 mm.
Vertical automatic 475 mm.
Center-axis distance 147 mm.

MANDRINO
Cone ISO 40
Main shaft diameter 88.88 mm
Diameter cutter holder shaft 22 mm.
No speeds 35/1800 rpm.
Continuous variation

ADVANCES
Nº Advances Continuous variation
Long.-transverse advances 0-1300 mm/min
Vertical feed 0-390 mm/min

RAPID ADVANCES
 Longitudinal and transverse 1300 mm/min
Vertical 750 mm/min

MOTORS
Main axle 5HP
Work and fast 2HP
Motor pump 0.12 HP

WEIGHTS
Weight max. on the table 300 Kgrs.
Net weight approximately 1700 Kgrs
Volume with packaging 6 m3



No. of items: 1

Loading costs not included.
