1 - Eccentric press - 45Tn
Sold
1 - Eccentric press - 45Tn
Location:
Description
Closing height: 290mm. Safety distance: 250mm.
Top die characteristics: length: 470 mm, width: 340 mm.
Main engine: 4 kw, max. Steering wheel: 105 r.p.m., Voltage: 380 V.
Clutch/brake: minimum-maximum pressure: 5- 6 bar.
Pneumatic system: minimum-maximum pressure: 4-10 bar.
CE Certificate.
Specifications
| Manufacturer | ESNA |
| Model | VFS/PN 45 |
| Year | 2004 |
| Condition | Used |
| Online Auctions | 2022-11-02 16:00:00 |
| Eccentric press, Closing force | 45 Ts. |
| Spindle regulation | 65 mm, travel from 2 to 90 mm. |
| Blows / minute | 52-157 strokes. |
| Die max weight | 90 kgrs. |
| Clutched max. | 561 min. |
| Approximate machine weight | 3.500Kg. |
