12 - Mechanical press -315 Tn
Sold
12 - Mechanical press -315 Tn
Location:
Description
Mechanical press -315 Tn
Technical Specifications
馃煝 Main Performance
馃煝 Tooling & Capacity
馃煝 Speeds
馃煝 Stroke & Adjustments
馃煝 Safety
馃煝 Weight
馃搳 Auxiliary Systems
馃敻 Drawing cushion
路Linear pressure-force relationship
馃敻 Balancing cylinders
路Linear pressure-force relationship
Specifications
| Manufacturer | AIDA |
| Model | 315/2MR/LD/TE 3 |
| Year | 2018 |
| Condition | Used |
| Online Auctions | 2026-09-03 16:00:00 |
| 路Nominal force | 3150 kN |
| 路Stroke at nominal force | 12.7 mm |
| 路Normal stopping position | TDC (Top Dead Center) |
| 路Max die size | 2250 脳 750 mm |
| 路Max die weight on slide | 10,200 kg |
| 路Max flywheel speed | 628.5 rpm |
| 路Slide speed (min-max) | 15 - 40 spm |
| 路Max clutch engagements per minute | 24 |
| 路Stroke | 250 mm |
| 路Slide adjustment | 160 / 50 mm |
| 路Shut height | 700 mm |
| 路Stopping time | 0.386 s |
| 路Safety distance | 618 mm |
| 路Total press weight | 58,000 kg |
| 路Up to approx. | 102 kN at 6 bar (0.6 MPa) |
